Advanced Drilling Technology Energy-efficient Intelligent Control SR235 Drilling Rig

Sany SR235-C10 rotary drilling rig is a high-performance engineering machinery and equipment, mainly used in large-scale construction projects such as bridge construction and high-rise building foundation treatment. It supports multiple working processes, including continuous drill pipe rotary drilling, spiral drill pipe rotary drilling, continuous geotechnical rotary drilling, as well as various crushing and continuous sampling processes, to meet the changing needs of different engineering projects.

Availability:

Quantity:



Inquire Add to Basket

Model:
SR235
Brand:
SNAY

一、Performance Parameters

Overall Specifications: The total machine height is 22.87m, the operating weight (including the maximum drill pipe) is 77t, and the dimensions in transportation state are 16385×3540×3660mm.
Drilling Capacity: The maximum hole-forming diameter is 2.0m, and the maximum hole-forming depth (friction rod/mechanical lock rod) is 68m/54m.
Power Head: The maximum output torque of the power head is 235kN·m, and the speed range is 5~26rpm.
Pressurization Performance: The pressing force of the pressurization system is 210kN, the pulling force is 215kN, and the stroke of the pressurization system is 5000mm.
Hoisting System: The lifting force of the main hoist (first layer) is 235kN, the diameter of the steel wire rope is 32mm, and the maximum speed is 70m/min; the lifting force of the auxiliary hoist (first layer) is 80kN, the diameter of the steel wire rope is 20mm, and the maximum speed is 70m/min.
Chassis Parameters: The total length of the chassis is 7265mm, the unfolded width is 4500mm, the track width is 800mm, and the tail swing radius is 4360mm.

二、Technical Features

High Efficiency and Energy Saving: It adopts an advanced hydraulic system and realizes real-time power distribution through power optimization control technology. It has fast action response speed and high fuel efficiency, with a comprehensive energy saving of 10%~15%. The imported large-displacement EFI engine is equipped with a high-power main pump to provide continuous and stable power output for the drilling rig.
Advanced Drilling Technology: The power head adopts multi-gear control technology for more efficient drilling. It is equipped with long guiding technology to ensure accurate drilling verticality, and the double buffer system further improves the safety protection capability of the drill bit.
Intelligent Control: It is equipped with the SANY-ADMS control system, adopting the first vertical touch display in the field of rotary drilling equipment. It uses a natural user interface design and picture-in-picture technology, making the operation information clear at a glance. The active prevention system can realize self-diagnosis and alarm and provide solutions; the EVI three-level management system can realize three-level network interaction among the machine owner, equipment and manufacturer to ensure the efficient operation of the equipment.
Reliability and Durability: The mast adopts a box-type structure, with strong torsion resistance and fatigue resistance. The 6th-generation drill pipe uses upgraded materials and is matched with a reinforcing ring structure, which increases the overall strength by 25% and has strong drilling capability in strongly weathered rock formations.

三、Operating Comfort and Safety

Operating Comfort: The console has a reasonable layout and adopts a humanized design, allowing operators to easily master the use of the machine and reduce labor intensity.
Safety: It is equipped with various safety protection devices such as an unbalanced force automatic detection and correction system, pressure sensors and temperature sensors, which can timely detect and eliminate faults to ensure the safety of the operation process.
