QAY500A
XC
Product parameter
| Working weight（kg） | 96000 |
| Engine power(kw) | 205kW/2100r/min |
| torque capacity | 2800N・m/1300r/min |
| Maximum turning speed | 0.8r/min |
| engine type | OM906LA |
| size | 20900x3000x4000mm |
| Maximum traveling speed | 80km/h |
| Minimum turning diameter | 30m |
| fuel consumption | 105L |
| Longest main boom | 84m |
Product photo
Xugong QAY500A crawler crane is an outstanding heavy lifting equipment with the following features:
Strong lifting capacity: The maximum rated lifting weight is 500 tons, the maximum lifting moment of the basic boom is 15190 kN·m, the 7-section elliptical cross-section boom, the full extended boom length reaches 84 meters, the longest main boom + auxiliary boom can reach 145 meters, which can meet various lifting operation requirements.
Good power performance: The cab engine model is OM906LA, with a rated power of 205 kW; the chassis engine model is OM502LA.E3A/1, with a rated power of 480 kW, the maximum driving speed is 80 km/h, the maximum climbing slope is 35%.
Excellent control performance: Equipped with advanced hydraulic system and precise control devices, using electro-proportional pilot control, CAN bus technology and PLC control technology, the operation is convenient and flexible, with high degree of automation and intelligence in control.
High safety and reliability: Equipped with various safety protection devices, such as overload limit, tilt limit, etc., the hydraulic system is equipped with hydraulic balance valves, hydraulic overflow valves, etc., the Hirschmann force limiter system can monitor the lifting operation parameters in real time to ensure operation safety.
Comfortable driving experience: Configured with a new generation of large space luxury driver's cabin, with a combined control console, full digital display instrument, Glaumer air-suspended seats, etc., the driving comfort and convenience are high.
