Do you want to know how rotary drilling RIGS work efficiently on construction sites? Its drilling tools, as key components, play an important role. Now, let's take a detailed look at the six key working principles of the drilling tools of the rotary drilling rig for you.

1


1. Power transmission: The engine of the drilling rig generates power, which is transmitted to the drill pipe through the transmission system, driving the drill string to rotate. Just like a car engine transmits power to the wheels, it provides "power" for the drill string to drill.


2. Rock breaking by drill bits: Different types of drill bits, such as rotary buckets and barrel drills, rely on their sharp cutting edges or breaking teeth to cut and break soil and rocks, easily "gnawing" through the strata.


3. Pressurized drilling: The drilling rig applies downward pressure to the drill string through a pressurization device, combined with rotation, allowing the drill string to penetrate deeper into the ground more quickly, just like using a screwdriver to tighten a screw. Pressure can accelerate the drilling speed.


4. Drilling debris loading: When rotary drilling tools such as rotary buckets are rotating and drilling, they will collect the broken drilling debris into the bucket. Once it is full, it will be lifted to the ground for unloading, completing one debris removal operation.


5. Verticality control: The sensors equipped on the drilling rig monitor the verticality of the drilling tools in real time. Once a deviation is detected, the system automatically adjusts to ensure the verticality of the borehole and guarantee the construction quality.


6. Drill pipe extension and retraction: The drill pipe can freely extend and retraction according to the drilling depth, which not only enables the drill pipe to reach the target depth but also facilitates its quick retraction after drilling is completed, thereby enhancing construction efficiency.


The drilling tools of the rotary drilling rig achieve efficient and precise drilling operations through a series of coordinated works such as power transmission and rock breaking by the drill bit. From power transmission to drill cuttings treatment, each link works closely together, making complex underground projects more efficient and convenient, and playing an indispensable role in modern construction.
