What Are The "hidden Functions" of Rotary Drilling RIGS

In infrastructure construction, rotary drilling RIGS are commonly used and crucial equipment. Most people are familiar with its main function of drilling and piling, but they are not aware that it also has many practical "hidden functions". These functions can significantly enhance work efficiency and quality in specific construction scenarios. Now let's introduce it in detail for everyone.

1. Free-fall hook rock breaking: In complex strata, there are often stones and isolated rocks that affect the formation of holes. The auxiliary hoist of the rotary drilling rig is equipped with an impact hammer. Through the free hook drop function, it uses the impact force to break down floating and isolated rocks, solving the problems that ordinary drill bits find difficult to handle and ensuring the quality of hole formation.

2. Follow-up pressurization and pulse rock breaking: Some high-end rotary drilling RIGS are equipped with this function. When facing hard strata, they can intelligently adjust the pressurization intensity and work in conjunction with pulse rock breaking to efficiently break rocks, ensuring smooth progress of drilling operations even under difficult working conditions.

3. Intelligent speed regulation and cruise control: The speed of the power head can be adjusted steplessly to adapt to different working conditions. The cruise control function ensures a constant speed during drilling in a stable formation, which not only guarantees the quality of the borehole but also enhances work efficiency.

4. Automatic pressure limiting and bottom contact protection: Excessive pressure during construction can easily damage equipment. The automatic pressure limiting function can monitor and control the pressure in real time. Bottom contact protection automatically adjusts the operation at the moment the drill bit touches the bottom to prevent excessive impact and extend the service life of the equipment.

5. One-click operation function: Functions such as one-click hole sweeping, soil shaking, and vehicle display simplify the operation process, reduce the reliance on the operator's experience, and enable beginners to quickly get started, thereby enhancing the overall construction efficiency.

6. Intelligent Interconnection and Fault Diagnosis: With the help of Internet of Things (iot) technology, rotary drilling RIGS can achieve intelligent interconnection. Through the mobile phone APP or remote management system, the working status of the equipment and construction data can be grasped in real time. When a malfunction occurs, the system automatically diagnoses and quickly locates the problem, facilitating maintenance.

These "hidden functions" of rotary drilling RIGS have greatly expanded their application scope and enhanced the safety, efficiency and intelligence level of construction. In actual operations, making full use of these functions can enable rotary drilling RIGS to achieve greater efficiency and facilitate the smooth progress of various infrastructure projects.
