The Characteristics of Pile Driving with Rotary Drilling RIGS

Rotary drilling RIGS, as the core equipment in modern pile foundation construction, are widely used in various foundation projects due to their unique working principle and performance advantages. The piling process of it presents many distinct features. The following is a brief analysis from six aspects.

1. High hole-forming efficiency: Rotary drilling RIGS rely on the rotation of the drill bucket to cut rock and soil, and in combination with the hydraulic system, they can quickly lift and unload soil. The hole-forming time for a single pile is usually shortened by more than 30% compared to traditional drilling RIGS, significantly improving the construction progress.

2. Wide adaptability to various strata: From clayey soil, sandy soil to moderately weathered rock layers, rotary drilling RIGS can cope with a variety of complex geological conditions and meet diverse construction needs by replacing different types of drilling tools.

3. Low construction pollution: During the operation, there is no need for a large amount of mud for wall protection, reducing the pollution of mud discharge to the environment. Moreover, the noise and vibration are relatively low, making it suitable for construction in sensitive areas such as urban residential areas.

4. Excellent pile formation quality: When the drill bucket cuts the rock and soil, it causes little disturbance to the hole wall, and the verticality of the formed hole is high. Combined with the hole cleaning process, it can effectively reduce the thickness of the sediment, providing a reliable guarantee for the bearing capacity of the pile foundation.

5. Strong operational flexibility: The equipment can rotate 360 degrees for operation, and the mast can be adjusted to tilt angles. It can be flexibly arranged in narrow Spaces or complex terrains, adapting to different construction scenarios.

6. High degree of automation: Modern rotary drilling RIGS are equipped with electronic control systems that can monitor parameters such as hole depth and verticality in real time, reducing human operation errors and improving construction accuracy.

In conclusion, rotary drilling RIGS for pile driving feature multiple characteristics such as high efficiency, environmental friendliness, flexibility, and high quality. They not only meet the requirements of modern engineering for construction efficiency but also satisfy the standards of green construction and quality control, making them indispensable high-efficiency equipment in pile foundation engineering.
